Covestro 385SX TPU Raw Material Oil Resistance Electrical Parts Application

Ask Lasest Price
Brand Name :	Covestro (Bayer)
Model Number :	TPU 385SX
Certification :	MSDS
Price :	USD5.5-6KG
Payment Terms :	T/T
Supply Ability :	500T
Delivery Time :	7-15days

Add to Cart

Product Details
Company Profile

Covestro 385SX TPU Raw Material Oil Resistance Electrical Parts Application

Products Description

Covestro 385SX TPU Raw Material Oil Resistance Electrical Parts Application

TPU Covestro 385SX High Wear Resistance High Cold Resistance Oil Resistance Water Resistance Mold Resistance Automotive Parts Application Electronic And Electrical Parts Application Hose Application

The TPU 385SX has extremely high wear resistance and can withstand long-term use and wear in harsh environments. Its unique molecular structure enables it to effectively resist wear and tear during friction, prolonging the service life of the product ‌. Has good oil, water and mold resistance, suitable for a variety of harsh environment ‌. By changing the ratio of each reaction component of TPU, products with different hardness can be obtained. With the increase of hardness, its products still maintain good elasticity and wear resistance ‌. TPU products have outstanding bearing capacity, impact resistance and shock absorption performance, and are suitable for a variety of applications requiring high strength and impact resistance ‌. TPU has a low glass transition temperature and still maintains good elasticity, flexibility and other physical properties at minus 35 degrees Celsius, which is suitable for applications in low temperature environment ‌.

product feature

TPU
385SX
Product information
Part Marking Code >TPU<
Color	NC
Material Shape	Pellets
Process	Injection molding
Features	·High strength
Application	·3C parts ·E&EApplications ·Screen packs ·Technical applications
Physical property	Standard	Value	Unit
Density	ISO 1183	1220	kg/m³
Hardness	Standard	Value	Unit
Shore Hardness A	ASTM D2240	89
Mechanical behavior	Standard	Value	Unit
Tensile Strength 200mm/min	DIN 53504	45.0	MPa
Tensile Strength 100%Strain 200mm/min	DIN 53504	6.2	MPa
Tensile Strength 300%Strain 200mm/min	DIN 53504	12.0	MPa
Elongation Break 200mm/min	DIN 53504	600	%
Tearing Strength 500mm/min	ISO 34	110	KN/m
Abrasion Resistance	ISO 4649	45	mm³
Injection molding		Value	Unit
Dry Temperature		110	℃
Melt Temperature		185~205	℃
Mould Temperature		20~40	℃

Application

Optical lighting

It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

Electronic appliances

It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

Mechanical equipment

It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields

Physical Property Parameter

Company Profile:

Dongguan Pengchen plastic Co., LTD Was Established On November 15, 2022, Located Indongguan City.

The Company Covers An Area Of More Than 400 Square Meters, And The Three warehouses Cover A Total Area Of 110000 Square Meters, With 50-60 Employees.

Our Company Is An Expert In The Field Of Plastic Raw Materials. A Professional Supplier Of modified Engineering Plastics Raw Materials. Engaged In R&d, Production And Sales Of engineering Plastics.

We Provide High-quality Plastic Raw Materials With Low Order quantity, Reasonable Price And Fast Delivery.

our Product Range Includes Engineering Materials And General Mater

Warehouse:

FAQ

How about our package?

1.All the packing can be customized.

2.Plastic bags for inner packing, good quality moisture-proof bags for outer packing.

3.We generally make 25kgs per small bag by accurate weight, this will be very convenient for the customer using. It’s very easy to

handle the dosage.

What are our business principles?

1.For the trial order, 1tons will be acceptable.

2.We will do our best for the customer as long as you choosing us.

3.We promise to solve all the problems during trading process, our quality and the products will be approved by your side.

What are the advantages of our shipping and delivery?

1.We make sure all the products will be inspected strictly before loading.

2.We will make the shipment within 7 days after confirm the payment.

3.We will recommend the best suitable shipping company for our customer from different countries. Saving cost for our client

Application	Electronics electrical appliances mobile phones cars
Grade	Injection Grade,Extrusion Grade
OEM/ODM	Accepted
